Paper Mill Equipment

Ahlstrom - ZX 60 U-2 24x24-26 Impeller: Staggered S/S 640 MM - (25.175") 7-Vane on Each Side Body: Stainless Steel Seal: Packing Weight: 5600 Lb. Dimension: 80"w 65"d 70"h Capacity: Head: 90 ft Flow: 19 000 US gpm Speed: 780 RPM Year: 1984Inlet: 24" Outlet: 24" Impeller Dia: 26"

Fiberprep Model No. ; SPM-800 Reverse Flow Pressure Screen; Stainless Steel Housing; Belt Driven; L-60 W-60 H-80; 2906 Lbs

24" Single Bank DSM Screen 120 Degree Incline 150 Mesh Screen Thickener 2'-0" Wide Slotted Feed Nozzle with Pnuematic Actuator.

Sulzer ZPP Size 51-600 Split Case Pump Constructed of 316SS Casing and Rotating Assembly. Size 24" x 28"; Materials 316 SS Casing and Rotating Element. Flow Characteristics: 19050 GPM; 64 FtHd; 700 RPM. Year 2000.

Bird 8 Pressure Screen 316 SS Casing 2–foil 316 SS Rotor and Basket .078" Holes Belt Drive on base includes 15 HP reliance motor 575v 60 HZ 1160 RPM.

Nash CL 402 Vacuum Pump; Iron; 1170 RPM

20' Diameter Black Clawson Pulper - Black Clawson; Capacity: 425 TPD at 3%; Hymac Turboflex Retrofit; Low Consistency Type: Continuous; Construction Material: Stainless Steel Interior and Exterior; One (1) Pulper Bottom Accept Chamber; One (1) Pulper Tub In Three (3) Sides Upright; One (1) Vokes Rotor 87-87.5" 8-Vanes S/S; One (1) Plug Made Of Carbon Steel; Four (4) Pulper Legs; One (1) Wear Plate; One (1) Extraction Plate. Spares Parts Available Separately: Vokes Rotor (2) Extraction Plates 3/8' and 1/2" Holes Gearbox Rotor Hub and Wear Plate.

Nash CL 6002G S/S 316 Clading: Body Cones Heads Shaft Diameter: 2.875" Position 4 Test #: Mc 01672 Ratio: 3.6 / 1 Drive Gear: 36 Teeth Driven Gear: 132 Teeth Vacuum Pump

Bauer Hydrasieve Inclined Thickener 71.5" Width; .04" Slots; Stainless Steel Plate; Stainless Steel Framing; L-83 W-65 H-90; 1400 Lbs

Ultrasorter Size 30 Tailings Screen by Black Clawson . New 2000. 316L Stainless Steel Construction. Belt driven 50 HP 1200 RPM motor. 2 ½% Maximum feed consistency. Approximately 30 BDTPD but capacity will vary according to the specific application. 6" (152mm) Inlet plate flange and 8" (203mm) accepts plate flange. Equipped with a screenplate with conically drilled holes. Can be used in a paper machine approach system secondary fiber screening or in a pulp mill screening system.

45-1B Sprout Waldron Disk Refiner Completely Rebuilt Immediately Available. Operates at 2500 HP and 4000 Volt.

Demineralized water system 167 GPM Reverse Osmosis Skid with anti-scalant chemical injection system. Manufacture Tenergy Christ. Includes controls: Alan Bradley micrologix 120 PLC with (2) 60" multimedia filters in excellent condition year 2004.

48" Vibrating Screen Mfg. Sweco with a 2.5 HP motor. Model# US48D88. Size: 1160 RPM 575 Volts.

292” Length 42”/60” Diameter Farrel Corporation Heavy Duty 2 wheel Roll Grinder with floating heads. Capacity: Max. Roll Dia. on center with full size wheel- 42”; Max. Roll Dia. above centerline- 60”; Min. Roll Dia. ground on centerline- 7”; Max. Roll Face ground- 292”; Max. Carriage traverse- 320” plus; Max. Crown/Concavity of roll - .400”; Grinder Bed: Material – High grade Meehanite Iron; Ways – inverted “V” type cast separately from bed close grained alloy construction; Anchoring – 4 rows of special leveling screws spaced on 4’ centers and an equal number of hold down bolts; Headstock: Material – High grade Meehanite Iron; Work speeds rpm programmable - 4 – 24rpm; Work Motor D.C. - 20 hp 400/1600 RPM; D.C. Drive new 2010 – ABB; Wheel heads: Grinding Wheel Dia. std. - 20”; Grinding Wheel Face std. - 3”; Spindle speed range - 700 – 1750 rpm;Grinding wheel motors D.C. - 15 hp; D.C. Drives - Harland Simon/ABB (new); Infeed Assemblies: Rough wheel infeed hand wheels for manual feeding on each wheel head.; Carriage: Material – High grade Meehanite Iron; Carriage Speed programmable - 2 - 60 ipm; Carriage Motor - 5 hp D.C.; D.C. Drive - Harland Simon / Electroflyte; Traverse screw diameter - 4 5/8”; Carriage Ways center-to-center - 72”; Over all width of each way - 8 ½”; Over all length of carriage - 98 ½”; Swing rest design on carriage to support adjustable pivot supports and wheel assemblies; Directional reverse of carriage travel with use of reversing and safety over travel limit switches; Dimensions: Approximate size of inertia block required - 45’ x 9’6” x 4’; Approximate weight of machine - 140000 lbs. Includes: Tooling and Roll Stands; Crowning Devices for Manual Crown Control; Engineering Files and Operating Manuals on Roll Grinder; One rebuilt electrical system containing all DC Drives Motors Magnetic Starters Relays Fuses more.; One New Operator station containing all operator controls; controls include on/off switches and speed control for grinding wheels forward/reverse e-stop and speed control for carriage. On/off and speed control for roll drive included on control panel. Machine can be seen under power mechanically and electrically turned over.

1500 hp Falk Gear Reducer Model 2135Y1-LS2 Ratio 3.433; RPM IN: 1750; RPM OUT: 510.

Voith Model No. GV 15 Pulper Gear Drive Ratio 5.86/1

Metso Optifiner Conica refiner; Size DF-1; Mfg 2006; Model No. Optifiner DF-1; L-60 W-36 H-45; 2774 Lbs

Nash H9 YEAR: 2007 Part #: 81U3645 Rebuilt by Nashmade In: USA Vacuum Pump

Goulds 3420 Pump Rotating Assembly; 20x20x30; 25" Diameter Stainless Steel 5-Vane Split/Staggered Skewed Impeller Stainless Steel Shaft; RH; L-93 W-40 H-32; 1618 Lbs.

17.5" Diameter Black Clawson High Density Cleaners
